Product Description
1. Features
★High effects energy-saving.
★High CRI 90~95 resume the true light appear for exhibiting goods;
★COB chips help the perfect light distribution curve;
★Green material without mercury,easy for recycle.
★DC drive without flicker,excellent for reading ,family,office
★Compared with halogen lamp,the downlight LED generate low heat ,high effects up to 90% energy for lighting.
2.Specification
|
Model |
HP7WSS |
HP12WSS |
HP20WSS |
HP30WSS |
|
LED Type |
COB LED |
COB LED |
COB LED |
COB LED |
|
LED Chips |
Sharp COB |
Sharp COB |
Sharp COB |
Sharp COB |
|
Input Voltage |
AC 180-240V (50/60Hz) |
AC 180-240V (50/60Hz) |
AC 180-240V (50/60Hz) |
AC 180-240V (50/60Hz) |
|
Power Factor |
>0.91 |
>0.91 |
>0.91 |
>0.91 |
|
Rate Power |
7W |
12W |
20W |
30W |
|
CCT |
2700K~6500K |
2700K~6500K |
2700K~6500K |
2700K~6500K |
|
Luminous Flux |
595lm |
1020lm |
1700lm |
2550lm |
|
CRI |
≧90 |
≧90 |
≧90 |
≧90 |
|
Beam Angle |
25°/40° /60°/120° |
25°/40° /60°/120° |
25°/40° /60°/120° |
25°/40° /60°/120° |
|
Surface Size |
Ø85*70mm |
Ø110*85mm |
Ø138*105mm |
Ø160*120 |
|
Hole Size |
70mm |
95mm |
120mm |
140mm |
|
Install Method |
Recessed |
Recessed |
Recessed |
Recessed |
|
Warranty |
Three Years |
Three Years |
Three Years |
Three Years |
