High Power aluminum housing IP67 outdoor recessed lightings led inground light-Product Center-EP LIGHTING INDUSTRY CO.,LTD.-

Product Description

1. Features



--Pure aluminium die casting for heat-sinking and 304 stainless steel for rings.

--AC/DC 12V, AC/DC 24V, 85-265VAC, 100-277VAC optional.

--8-120 degree beam angle optional.

--RGB inner control/DMX control optional.
--IP67 Waterproof grade.

--Three years warranty,high quality guaranteed.





2.Specification

Model

EP-IG3W01

EP-IG7W01

EP-IG12W01

EP-IG18W01

EP-IG24W01

EP-IG36W01

LED Type

1W High Power

1W High Power

1W High Power

1W High Power

1W High Power

1W High Power

LED Chips

Bridgelux

Bridgelux

Bridgelux

Bridgelux

Bridgelux

Bridgelux

Input Voltage

DC 24V or 100-277VAC

DC 24V or 100-277VAC

DC 24V or 100-277VAC

DC 24V or 100-277VAC

DC 24V or 100-277VAC

DC 24V or 100-277VAC

Rate Power

3W

7W

12W

18W

24W

36W

Color

Single color(Red, Green, Blue, White) or RGB

Housing

304 Stainless Steel Ring; Die Cast Aluminum lamp body

Beam Angle

8--120° optional

Surface Size

φ100*H80

φ150*H95

φ180*H95

φ200*H100

φ220*H100

φ300*H100

Hole Size

70

130

160

185

205

295

Others

built-in fittings included

built-in fittings included

built-in fittings included

built-in fittings included

built-in fittings included

built-in fittings included

Warranty

Three Years

Three Years

Three Years

Three Years

Three Years

Three Years
