Product Description

1. EP LED Wall Pack light Features

▼ It's major to replace the conventional wall pack light.

▼ Replaces 250W metal halide lamps.

▼ Fixture material is Die-casting aluminum + glass refractor.

 High lumen output, 95-105LM/W.

 Beam angle 120 degrees.

▼ 80+ CRI. CRI>95 can be customsized.

▼ Recessed outlet box or wall surface mounting.

▼ CCT 3,000K 4,000K 5,000K.

▼ IP 65 Rating.

▼ No RF interference, No IR/UV radiation, no mercury pollution.

2. Applications

EP glass refractor LED wall pack is a classic architectural shape wall pack, designed to provide security lighting and general purpose lighting in

parking garages,

public areas,

schools,

hospitals,

hotels and other commercial and residential applications.

3.Specification

Model

WPGR040

WPGR060

WPGR090

LED Type

SMD 2835 or 5730

SMD 2835 or 5730

SMD 2835 or 5730

LED Chips

LM80 approved

LM80 approved

LM80 approved

Mount

Recessed outlet box Or wall surface

Recessed outlet box Or wall surface

Recessed outlet box Or wall surface

Input Voltage

AC 100-277V (50/60Hz)

AC 100-277V (50/60Hz)

AC 100-277V (50/60Hz))

Rate Power

40±1W

60±1W

90±1W

Equivalent Wattage

150W

250W

400W

CCT

2700K~6500K

2700K~6500K

2700K-6500K

Light Efficiency

95-105lms/W

95-105lms/W

95-105lms/W

Material

Tempered glass and Die-casting aluminum

Tempered glass and Die-casting aluminum

Tempered glass and Die-casting aluminum

Operating Temp.

 -30130°F (-3454°C)

 -30130°F (-3454°C)

 -30130°F (-3454°C)

Operating Humidity

20–85% RH, non-condensing

20–85% RH, non-condensing

20–85% RH, non-condensing

Dimension (no pin)

  L335*H250*D200mm

 L452*H250*D200mm

L452*H250*D240mm

Waterproof

IP65

IP65

IP65

Warranty

Five Years

Five Years

Five Years
