Product Description

1. Features

These series tubes are the truly retrofit kits for the traditional fluorescent with electronic ballast and magnetic ballast for North America market. The plastic enclosure is extremely safe, can perfectly pass the LVD testing. It is the perfect LED tube choice.

2. Specification

Model

T8-22W1200XY-KZ

LED Type

SMT 2835 LED

LED Chips

Epistar Chips

Base Type

G13

Input Voltage

AC 100-277V (50/60Hz)

Driver Efficiency

>90%

Rate Power

22±1W

CCT

2700K~6500K

Luminous Flux

2420 Lm

CRI

80

Beam Angle

270°±5°

PF

≥0.9

Dimension

L 1198mm26mm

Material

High Purity PC + Pure Aluminum Sink

Weight

220g

Warranty

Five Years

SCDM

≤7dB

Withstand Voltage

AC 4,000V

Insulation Resistance

4MΩDC 500V
