Product Description
1. Features
1) Die-casting Aluminum+PMMA lens design, good heat-sinking;
2) 4000V testing passed;
3) Multi beam angle for choice like 10º/15º/25º/45º;
4) Dim function is optional.
5) High CRI, over 93.
2.Specification
|
Model NO |
EP-AR111-2-1201 |
EP-AR111-3-1201 |
EP-AR111-1206 |
||
|
WATTS W |
12W |
12W |
12W |
||
|
Lumens Output |
500-700lm |
600-800lm |
500-700lm |
||
|
LIGHT COLOR (CCT) K |
2700-6500K |
2700-6500K |
2700-6500K |
||
|
BEAM ANGLE ˚ |
15º/25º/45º |
10º/15º/25º/45º |
15º/25º/45º |
||
|
LED Chips |
CREE |
CREE |
OSRAM |
||
|
COLOR ACCURACY (CRI) Ra |
>93 |
>93 |
>93 |
||
|
Warranty |
3 years |
3 years |
3 years |
||
|
LED DRIVER POSITION |
external Driver, connect with wire |
||||
|
INPUT VOLTAGE (AC/DC) V |
AC/DC 12V or 100-240V |
||||
|
DIMENSION (mm) |
Ф111*34mm |
Ф111*34mm |
Ф111*42mm |
||
|
Material |
Die-casting Aluminum+PMMA lens |
||||
|
Package |
outer box:470*355*380mm; 60pcs/ctn |
||||
APPLICATIONS
