Product Description

1. Features



--We only use Samsung SMD5630 with CRI 83 as light source,creat high lighting performance.

--Pure aluminium die casting fixture with heavy material, never use platic / cheap ones.

--NO FLICKERS, Each light creat a friendly & smooth lighting

--2.5inch, 3inch, 4inch, 5inch, 6inch, 8inch, replacing the traditional CFL downlight directly.

--The SMD LED downlight comes with 90°wide beam angle.
--Frosted anti-glare PMMA lens adopted for high LOR.

--Three years warranty,high quality guaranteed.





2.Specification

Model

HP7WSN(IP65)

HP10WSN
(IP65)

HP12WSN
(IP65)

LED Type

SMD 5630 LED

SMD 5630 LED

SMD 5630 LED

LED Chips

Samsung

Samsung

Samsung

Input Voltage

AC 180-240V (50/60Hz)

AC 180-240V (50/60Hz)

AC 180-240V (50/60Hz)

Power Factor

>0.91

>0.91

>0.91

Rate Power

7W

10W

12W

CCT

2700K~6500K

2700K~6500K

2700K~6500K

Luminous Flux

570lm

820lm

1030lm

CRI

83

83

83

Beam Angle

120°

120°

120°

Surface Size

Ø90*60mm

Ø110*80mm

Ø110*80mm

Hole Size

75mm

95mm

95mm

Install Method

Recessed

Recessed

Recessed

Warranty

Three Years

Three Years

Three Years
