INTEGRATED T5 LED TUBE-Product Center-EP LIGHTING INDUSTRY CO.,LTD.-

Product Description

1. Features

EP INTEGRATED T5 LED TUBE are suitable for indoor using such as office, store, library, hospital and etc. The aluminum housing is with significant heat-sinking performance to help the LED keep cool and stable working status.


2.Specification

Model

T5-EP30-36D-5W

T5-EP60-48D-8W

T8-EP90-72D-13W

T8-EP120-96D-16W

LED Type

SMD 2835 LED

SMD 2835 LED

SMD 2835 LED

SMD 2835 LED

LED Chips

Epistar Chips

Epistar Chips

Epistar Chips

Epistar Chips

Input Voltage

AC 85-265V (50/60Hz)

AC 85-265V (50/60Hz)

AC 85-265V (50/60Hz)

AC 85-265V (50/60Hz)

Driver Efficiency

>90%

>90%

>90%

>90%

Rate Power

5±1W

8±1W

13±1W

16±1W

CCT

2700K~6500K

2700K~6500K

2700K~6500K

2700K~6500K

Luminous Flux

80lm/w

80lm/w

80lm/w

80lm/w

CRI

80

80

80

80

Beam Angle

180°±5°

180°±5°

180°±5°

180°±5°

PF

≥0.9

≥0.9

≥0.9

≥0.9

Dimension

0.3M/1FT

0.6M/2FT

0.9M/3FT

1.2M/4FT

Material

Half PC+Half AL

Half PC+Half AL

Half PC+Half AL

Half PC+Half AL

Warranty

Two Years

Two Years

Two Years

Two Years
